Agilent Technologies 5110 ICP-OES

Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 237
8Support Parts
Mains Module – Power Supplies
Mains Module – Power Supplies
Return to step 17
1
7
6
5
4
2
3
Item Description Part Number Remark
1 Assy Mains Power Module G8010-67300 Includes 24V power supply, poly heater and RF power
supply control
2 Assy RF Power Supply G8010-87301
3 Assy PCA ICP SSRF PSU Interface G8010-65204
4 Connector AC Power Inlet G8010-60502
5 Switch-Rocker 2-Pole 240VAC 20A Panel Mt G8010-60503
6 Filter Power Line G8010-60504
7 Assy Standby Switch G8010-60225 Includes switch, loom and mounting hardware
