284 Agilent Restricted Agilent 5110/5100 ICP-OES Service Manual
10 Installation Guide (5110 ICP-OES)
Instrument performance tests
Blank
This solution should be prepared from pure distilled, de-ionized water with 1% analytical reagent
grade nitric acid (HNO
3
).
Rinse
This solution should be prepared from pure distilled, de-ionized, acidified water or use the Blank
solution.
Performance tests
The performance of the instrument is determined by these tests:
• Resolution test
• SBR/SRBR
• Precision
All tests should be run under stable ambient environmental conditions.
Make sure torch, nebulizer, Spraychamber, pump tubes etc. are clean and in good working
condition before starting up the instrument.
Polychromator heater and boost gas purge should be turned on for at least 2 hours before
running all tests.
Plasma should be on for at least 10 minutes before testing. The Peltier cooling should be on for
at least 5 minutes before testing.
A Detector Calibrate (Dark Current scan) should be completed before testing.
A valid Wavelength Calibration must be run before testing.
Argon ratio should be measured and be within ±0.5 of the factory setting.
Instrument conditions
All tests use the following conditions unless otherwise stated.
Pb 5
Se 5
Sr 5
Zn 5
Element Concentration (ppm)
Instrument condition Specification
Power 1.2 kW
Plasma gas 15 l/min
Auxiliary gas 1.2 l/min
Nebulizer flow setting 0.8 l/min
Pump tubing White-White (inlet), Blue-Blue (outlet)
Pump speed 12 rpm
