Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 67
4 Removal/ Installation, Replacement and Adjustment
Instrument covers
Instrument covers
Section Contents:
Left hand side cover 67
Left hand top cover 68
Chimney 69
Right hand side cover 70
Top right hand cover 71
Front left lower cover 73
Torch compartment door 73
Left hand side cover
1 Loosen 2 torx 20 screws.
2 Pull bottom of cover out and down to remove from locating tabs.
