242 Agilent Restricted Agilent 5110/5100 ICP-OES Service Manual
8Support Parts
Plasma compartment
Plasma compartment
Return to step 17
Item Description Part Number Remark
1 SSRF Assy G8010-60610
2 Assy Current Sensor Work Coil G8010-67613
3 Assy Work Coil G8010-68103
4 Assy Plasma Igniter G8014-67010 Not visible, behind SSRF Assy
5 Assy Switch RF Door Interlock G8010-60291 Complete 2 switches wired with connector
6 RF Seal Plasma Compartment G8010-60642 8 lengths supplied for 1 door seal
7 Seal Plasma Compartment G8010-60643 1.2 metres length for 1 door seal
8 Handle Torch Loader G8010-67078
9 Hinge offset type A G8010-60606 Single hinge only
10 Assy Water Connection SSRF G8014-60097 Includes SSRF water quick connect fitting, tubing and
barb fitting for RF box
NS Mount Insulator Igniter G8010-60615 Ceramic igniter on torch loader
