Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 49
3 General Information
Optics
Optics
Section Contents:
Description 49
Pre optics assembly 51
Polychromator assembly 52
Camera assembly 54
Description
The 5110 spectrometer optical system features a temperature controlled purged optics
assembly allowing analysis over a full range of wavelengths from 166.798 nm to 784.307 nm.
The optical system of the Agilent 5110 spectrometer accepts light radiated from the plasma
and separates it into discrete wavelengths.
The 5110 spectrometer optical system construct includes:
• Polychromator heater box
• Pre-optics assembly
• Echelle polychromator assembly
• Camera assembly
Agilent 5110/5100 Optical System Specification
Polychromator
Type Echelle with cross dispersing prism
Focal length 400 mm
Collimating mirror 75 mm diameter off-axis parabolic (masked to suit f6.7 aperture)
Focusing mirror 87 mm diameter off axis parabolic Dispersing element
Wavelength range 166.798 nm through 784.307 nm
Cross-dispersing element CaF2 prism
Entrance slit (fixed) 51m wide x 29m high 15 Degree off axis parallelogram
Stray light 10,000 ppm Ca solution gives equivalent concentration of < 2 ppm of As @
193.696 nm
Pre-optics
Radial Vertical scan 0-20 mm in 1mm increments (8mm default)
Axial Factory aligned optical components in vertical and horizontal plane.
Vertical Dual View (VDV) Rotating beam combiner utilizing Aluminium coated mirror for Axial
transmission and pass through for Radial mode.
Synchronous Vertical Dual view
(SVDV)
Rotating beam combiner utilizing Dichroic Spectral Combiner (DSC)
technology for Axial/ Radial synchronous mode.
