Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 285
10 Installation Guide (5110 ICP-OES)
Performance Test Procedure:
The spraychamber and nebulizer are assumed to be clean and well wetted.
In order to perform these tests a full sample introduction system must be installed and a
plasma must be ignited.
1 Ignite a plasma.
The instrument will turn on nebulizer flow. At the completion of the full purge the nebulizer
gas solenoid will turn off. The igniter should start to spark and a plasma should form. The
peristaltic pump will start up. Leave the plasma running and allow the instrument to warm up
for 10 minutes before moving on to the next step.
Performance Test Procedure:
1 Turn on the PC and start the ICP Expert 7 software.
2 When the ICP Expert 7 software has loaded, select the Instrument button on the tool bar.
3 Click on Tests tab and tick the test check box.
4 Click on Run Tests and follow the prompts to introduce samples.
5 A report will be displayed when test sequence has completed.
The report will be saved with a date and time code as a txt file under:
C:\ProgramData\Agilent\ICPExpert\ReportData-Serialno\
TestResults_date – yyyy-mm-dd-time.txt
6 To save the report as a PDF click on “Export Report to PDF”.
Viewing height 7mm
Points/peak 2
Replicate read time 5 secs
Replicates 10
Background correction None
Sample delay 25s
Stabilization time 15s
Rinse time 30s
Polychromator boost purge On
Snout purge On
Instrument condition Specification
