70 Agilent Restricted Agilent 5110/5100 ICP-OES Service Manual
4 Removal/ Installation, Replacement and Adjustment
Right hand side cover
5 Pull chimney forward to release from rear tabs.
Right hand side cover
1 Pull utilities cover to the left to remove from locking pins.
2 Loosen rear torx 20 screw.
3 Loosen front torx 20 screws.
To Next Page
