Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 287
10 Installation Guide (5110 ICP-OES)
Analytical Tests
blank solutions. The Instrument Test software will use the data from this worksheet to calculate
the Full Width at Half Maximum - FWHM (that is, the width of the peak at half its height). Results
are generated and displayed in the Installation Performance tests results.
The spectral resolution (FWHM) should be less than or equal to the following:
Signal to Background Ratio (SBR/SRBR)
Signal to Background ratios are calculated using two different methods depending on the level
of background for a given element. Calculations are as follows:
• SBR = (Total intensity - blank intensity) / blank intensity
• SRBR = (Total intensity - blank intensity) / Square Root blank intensity)
Result should be greater than or equal to the following:
Wavelength (nm) Agilent 5110 ICP-OES (pm)
Al 167.019 9.7
N 174.213 9.4
As 188.980 8.2
C 193.027 11.5
Mo 202.032 8.2
Cr 206.158 13.4
Zn 213.857 8.7
Pb 220.353 9.5
Co 228.615 17.2
Ba 230.424 9.4
Mn 257.610 13.3
Mn 260.568 20.3
Cr 267.716 11.0
Cu 324.754 25.0
Cu 327.395 14.2
Sr 338.071 33.5
Ba 455.403 44
Sr 460.733 36
Ba 493.408 36
Ba 614.171 42
Ar 675.283 74
K 766.491 80
Table 2 5110 Axial view
Element Std Spraychamber and Nebulizer Calculation method
As 188.980 208 SRBR
Se 196.026 159 SRBR
Zn 206.200 234 SRBR
