G4208A User’s Guide 13
1 Start-up Information
Physical Specifications
Physical Specifications
Table 3 Physical Specifications
Type Specification Comments
Weight 0.8 kg (1.76 lbs)
Dimensions
(width × depth × height)
130 × 225 × 35 mm
(5.1 × 8.9 × 1.4 inches)
Line voltage 22 VDC, ± 10 % via CAN
Power consumption 7 W
Ambient operating temperature 4 – 55 °C (39 – 131 °F )
Ambient non-operating temperature -40 – 70 °C (-40 – 158 °F)
Humidity 95 %, at 25 – 40 °C (77 – 104 °F) Non-condensing
Operating altitude Up to 3000 m (9842 ft)
Non-operating altitude Up to 4600 m (15092 ft) For storing
Safety standards: IEC, CSA, UL, EN Installation category II, pollution
degree 2.
For indoor use only.
Research Use Only. Not for use in
Diagnostic Procedures.
This product with serial numbers DE and MY16355458 and below contains an
TFT LCD assembly which is backlit by a mercury fluorescent lamp which
contains mercury, and must be managed, recycled, and/or disposed in
accordance with all applicable laws, ordinances, and regulations. For information
on how to recycle or dispose of the mercury lamp contained in this product, or if
you have additional questions on the mercury contained within this product,
contact Agilent customer service.
Starting with MY16375501 the product is RoHS compliant and uses a LED
display (which does not contain mercury) that requires normal local disposal
regulations.
