Instant Pilot Display and Keyboard Layout
Instant Pilot Display and Keyboard Layout
Figure 4 on page 21 shows the layout of the display and the keys. All has been
arranged in functional groups around the display.
Figure 4 The Agilent Series Instant Pilot - Layout
1
2
3
4
5
6
7
8
9
NOTE
The displayed module’s naming may change depending on the installed
firmware and the connected modules (1100/1200/1260/1290).
