G4208A User’s Guide 53
1 Start-up Information
Switching from G1323A/B Control Module to Instant Pilot
Switching from G1323A/B Control Module to
Instant Pilot
The Instant Pilot is a further development of the G1323A/B Control Module which
has been reworked and structured in a new modern way (more like an Agilent
ChemStation). Therefore some areas of the G1323A/B Control Module appear in
different areas.
Table 10 on page 53 shows the main changes.
Table 10 G1323A/B Control Module vs. Instant Pilot Functions
G1323A/B Control Module G4208A Instant Pilot Comment
Analysis screen Welcome screen - Status
Analysis screen - Settings / Method Welcome screen - Method
Analysis screen - Time Table Welcome screen - Method - Time Table
Analysis screen - Sequence Welcome screen - Sequence
Analysis screen - Vial range Start button - Sample Range
Analysis screen - ON/OFF (on various
screens)
Control button - System ON/OFF and
System: Get Ready (on various screens)
System screen Welcome screen - Logbook
System screen - Control Control button (on various screens)
System screen - Configuration Welcome screen - More - Configuration
System screen - Tests Welcome screen - More - Mainte-
nance/Diagnostics
System screen - Records Welcome screen - Details
Welcome screen - More - Maintenance -
System
System Info Product number, serial number, board ID
and firmware revision
System screen - Records - EMF Welcome screen - More - Maintenance -
[Module] - EMF Setup
System screen - Records - Logbooks Welcome screen - Logbook
Welcome screen - More - Maintenance -
[Module]
System, Controller, Modules EMF
Events, Errors Events and Maintenance
Entries
System screen - Records - FW Update Welcome screen - More - Maintenance -
System - Single/Wizard - PN/SN
Firmware updates and Product and
Serial Number change
