G4208A User’s Guide 16
1 Start-up Information
Adding the Instant Pilot to an Agilent HPLC Module
Adding the Instant Pilot to an Agilent HPLC
Module
To attach the Instant Pilot to an Agilent HPLC module, the provided adapter plate
is required.
The CAN connectors are similar to LAN adapter connectors
Do not insert LAN connectors into the CAN or vice versa, since the CAN
uses 24 V and might damage the LAN card.
The CAN bus does not support hot plugging or unplugging.
Unwanted or unexpected behavior of the instrument.
Switch off all HPLC modules, before plugging/unplugging the Instant Pilot.
Preferred orientation of the Instant Pilot is hanging at the HPLC modules.
When inserting the adapter to an Agilent Wellplate Autosampler or Fraction
Collector, the Instant Pilot must be removed first. Otherwise the Autosampler
door cannot be opened.
