G4208A User’s Guide 61
2 Working with the Instant Pilot
Printing To USB Flash Drive
Table 11 Overview of Printable Information
Dialog Name Button
File Name in
PRINT-
OUT
Comment
System Details Print SYSINFO.MHT via Details button, see Figure 37 on page 60
Method File - Print METHOD.MHT Contains Method, Timetable, Inj.Programm
Sequence File - Print SEQUENCE.MHT
Logbook Print LOGBOOK.MHT
Plot Print PLOT.MHT via Status button
single or multiple, pressure, composition, tempera-
ture, detector signals
SCANs via Control button
• DAD/MWD Scan Print DETSCAN.MHT sample scan
• VWD Scan Print DETSCAN.MHT blank (reference) and sample scan
• FLD Scan Print DETSCAN.MHT Excitation or Emission scan
Calibrations via More button and Maintenance
• DAD Calibration Print DADCALIB.MHT
• MWD Calibration Print MWDCALIB.MHT
• VWD Calibration Print VWDCALIB.MHT
• FLD Calibration Print FLDCALIB.MHT not implemented yet
Diagnostic via More button and Diagnosis
shows diagram, actions, results and sign-off, see
Figure 38 on page 63
• DAD/MWD Intensity Print DIAGRES.MHT
• DAD/MWD Holmium Print DIAGRES.MHT
• DAD/MWD Dark Current Print DIAGRES.MHT
• DAD/MWD Cell Test Print DIAGRES.MHT
• VWD Intensity Print DIAGRES.MHT with Raw Sample / Reference Signal Counts
• VWD Holmium Print DIAGRES.MHT
• FLD Intensity Print DIAGRES.MHT
