Operational Checks
M4735A Heartstream XL Defibrillator/Monitor 11-3
11
Using External Paddles
To perform the Shift/System Check using external paddles:
1. Turn the Heartstream XL off.
2. If routinely used, insert a Data Card into the Heartstream XL.
3. Unplug the AC power cord.
4. Insert a charged battery.
5. While pressing , turn the Energy Select knob to Manual On
to start the test.
127( If the paddles are in the holders and the message "Place Paddles in Pockets"
appears, adjust the paddles to improve contact. Poor contact may be due to
due to clinical use (e.g. oxidation or residue on either the connectors or pad-
dles). If the message continues to appear, contact a certified technician.
6. Follow the prompts on the display to proceed with the test. If the
message 6HUYLFH8QLW appears, do not use the device, and call for service.
The test takes less than a minute to complete. When it is done, a report
is printed, as shown in Figure 11-1.
)LJXUH6KLIW6\VWHP&KHFN5HSRUW8VLQJ([WHUQDO3DGGOHV
:$51,1* %HVXUHWRVDIHO\GLVFKDUJHH[WHUQDOSDGGOHV
Strip
Shift/System Check 8 Jan 1999 13:52:17 M4735A Serial Number:00000001
Last Checked 25 Nov 00 1:25:30 Pass Qty/Check List:
urrent Tests: Pass
General System Test: Pass
ECG Test: Pass
Backup Power Test: Pass
SpO2 Test: Pass
Data Card Test: 2:07 (h:mm remaining)
Defib Test: Pass/External Paddles
Pacer Test: Not tested
___ Defibrillator Inspection
___ Cables/Connectors
___ Paddles/Pads
___ Monitoring Electrodes
___ Charged Batteries
___ AC Power Cord
___ Printer Paper
___ Data Card
___ Ancillary Supplies
___ SpO2 Sensor
