Getting Acquainted
2-2 Getting Started
Getting Acquainted
This section provides an overview of the Heartstream XL controls, connec-
tions, and display layout. A review of control functionality is also provided.
Basic Orientation
Review the figure for a general layout of the controls, where the patient cables
connect, and where to insert the battery and Data Card.
Figure 2-1 Basic Orientation (Front)
AC Power
Batt Charge
Print Strip
Event
Summary
ECG Size
Pacer
Rate
Mode
Start/Stop
Output
Data Card
Battery
Volume
Mark
Patient Cable Connector
Energy Select Knob
Speaker
To Next Page
