Getting Acquainted
2-6 Getting Started
Display Buttons
127( Synchronized cardioversion and pacing controls only function when Manual
Mode is enabled.
Energy
Select
Knob
Can enable both Manual Mode and AED Mode. The AED
On position activates AED Mode. Manual On enables
Manual Mode, synchronized cardioversion and pacing
(optional).
Button below the display (far left) that enables
synchronized cardioversion when first pressed in Manual
Mode; disables synchronized cardioversion when pressed
again.
Activates the pacing function buttons (as indicated by the
green LED), allowing you to use the buttons below to
define pacing rate, mode, and current output. Also turns off
the Pacer function when pressed a second time.
Adjusts the pacing rate.
Starts pacing. Delivers pacer pulses when
first pressed; stops pacing when pressed
again.
Selects Demand or Fixed Mode for pacing.
Adjusts the current output for pacing.
Rate
Start
Stop
Mode
Output
