Defibrillating
M4735A Heartstream XL Defibrillator/Monitor 3-13
3
Delivery of the shock is confirmed by the message 6KR FN'HOLYHUHG and the
shock counter is updated.
)LJXUH6KRFN'HOLYHUHG'LVSOD\
Automatic Re-analysis On
If Automatic Re-analysis is on, the Heartstream XL analyzes the ECG fol-
lowing delivery of the shock. You are prompted to press , if an addi-
tional shock is advised. This cycle repeats until the rhythm converts or a
shock series is complete. (A shock series may be configured to 2, 3, or 4
shocks.)
Automatic Re-analysis Off
If Automatic Re-analysis is off, the Heartstream XL monitors the ECG for
potentially shockable rhythms provided Rhythm Monitoring is on and
prompts you to press if one is detected. You can initiate analysis
without being prompted by pressing .
LEAD
SELECT
SpO2
ON/OFF
HR
ALARM
120
Pads
Shocks: 1
00:00:40
Shock Delivered
6+2&.
$1$/<=(
$1$/<=(
