Symbol Definitions
13-14 Specifications & Safety
Symbol Definitions
The following table lists the meaning of each symbol shown on the
Heartstream XL and the M3516A battery:
7DEOH'HILEULOODWRUDQG%DWWHU\6\PEROV
Symbol Definition
Defibrillation Shock.
Attention - See operating instructions in user’s guide.
Input.
Meets IEC type BF leakage current requirements and is defibrilla-
tor protected (Patient Applied Part is isolated and defib-proof
suitable for direct patient contact except the heart or major
arteries.)
Meets IEC type CF leakage current requirements and is defibrilla-
tor protected (Patient Applied Part is isolated and defib-proof
suitable for direct patient contact including the heart and major
arteries).
Alarms are active.
Alarms are inactive.
Recyclable material.
!
