Selecting a Sensor
5-4 Monitoring SpO2
Selecting a Sensor
Table 5-1 shows the SpO
2
sensors that may be used with the Heartstream XL.
7DEOH$SSURYHG6HQVRUV
127( To use Nellcor sensors, you must connect the M1943A Nellcor Adaptor
patient cable to the Heartstream XL. (See “Connecting the SpO2 Patient
Cable” on page 10-5.)
Sensor Type Patient Patient Size Ideal Site
M1191A Reusable Adult > 50 kg Finger
M1192A Reusable Small adult
Pediatric
15-50 kg Finger
M1194A Reusable Pediatric
Adult
> 40 kg Fleshy part
of ear
M1903A/B
(Nellcor D-20)
Disposable Pediatric 10-50 kg Toe/Finger
