Figure 2-6 Manual Mode Display Layout
Connecting to Power
The Heartstream XL is powered by AC Power and the M3516A battery. Prior
to inserting the battery, make sure that the battery is charged and has been
properly maintained (See “Battery Maintenance” on page 11-7). It is
recommended that a second, charged battery be available at all times.
127( The Heartstream XL will take longer to charge to the desired energy level
when using only AC Power and without the battery.
HR ALARM
LEAD
SELECT
SYNC
ON/OFF
CHARGE SHOCK
Shocks: 0
00:15:02
Sync
114J
132
86
System Message
Momentary Message
Lead II
SpO
2
value
SpO
2
alarm
Pleth Bar
Pulse Rate
Heart Rate
ECG
Sync Display
Current Charge
Shocks Delivered
Incident Timer
Lead
Displayed
HR Alarm
Defibrillation
Softkeys
SPO2
ON/OFF
ECG Gain
Pulse 130
SPO2
ALARM
To Next Page
