Using 3 or 5-wire ECG Leads
M4735A Heartstream XL Defibrillator/Monitor 7-3
7
Using 3 or 5-wire ECG Leads
To prepare for synchronized cardioversion using 3 or 5-wire ECG leads,
perform the following steps:
1. If needed, insert a Data Card (as described in “Using a Data Card
(Optional)” on 2-13).
2. Apply monitoring electrodes, if desired. (See “Applying Monitoring Elec-
trodes” on page 4-4.)
3. Turn Energy Select knob to Manual On.
4. Connect the ECG cable to the Heartstream XL. (See Figure 6-3.)
5. Press Sync On.
6. Use to select the best lead that displays a large QRS complex. (See
“Selecting the Lead” on page 4-7.)
/($'
6(/(&7
