Getting Acquainted
M4735A Heartstream Defibrillator/Monitor 2-3
2
Figure 2-2 Heartstream XL (Back)
127( If your Heartstream XL does not have the SpO
2
or Pacing option, disregard
these controls and the related information described in this section.
AC Power
ECG Input Jack
SpO
2
Connector
ECG Connector
Printer
