System Messages
M4735A Heartstream XL Defibrillator/Monitor 12-3
12
/HDGV2II l The monitoring electrodes are not
applied.
l The monitoring electrodes are not
making proper contact with the
patient.
l The monitoring cable is not con-
nected.
l Check the monitoring electrodes are
properly applied.
l Check the monitoring cable is prop-
erly connected.
1R3DGV The multifunction defib electrode pads
are not properly connected to the Heart-
stream XL.
Check the pads cable connection.
3DGV&DEOH2II The pads cable is not connected to the
defibrillator.
Check pads connector is locked in place.
3DGV2II The pads are not making proper contact
with the patient.
Make sure the pads are properly applied
to the patient.
3DFHU)DLOXUH The pacing system is not functioning. Remove the device from active use and
call for service.
3DFHU 2XWSXW/RZ High patient impedance is resulting in the
pacer delivering less current to the patient
than specified in the output current set-
ting.
Check the pads are applied properly.
1R3DGGOHV&RQQHFWHG The paddles are not properly connected to
the Heartstream XL.
Check that external paddles are con-
nected.
7DEOH6\VWHP0HVVDJHV&RQWLQXHG
Message Description Corrective Action
