Key Reference
N
Chapter 5186
N
Negative
Supported PSG-A Series
This key enables you to select a negatively sloped ramp, or sawtooth, as the modulation
waveform for the internally generated, ac-coupled, signal.
Preset N/A
Range N/A
Location Page 230, Page 235, Page 237, Page 240
Remarks None
Noise
Supported PSG-A Series
Use this softkey to access a menu that enables you to specify a noise type as the
modulation waveform for the internally generated, ac-coupled signal.
Preset Uniform
Choices Uniform or Gaussian
Location Page 230, Page 235, Page 237, Page 240
Remarks The selected waveform applies only to the path configuration you have
currently selected.
Noise is generated as a peak to peak value; the RMS value is about
80.0% of the displayed value.
