Key Reference
T
Chapter 5220
T
Trans/Recv Pace None Xon
Supported All
This softkey enables you to determine whether any pacing is acknowledged by the
RS-232 transmit channel. If Xon pacing is used, the system will suspend transmitting
data upon receiving an Xoff character until an Xon character is received. The signal
generator may not be responsive to other channels, or to the front panel, while
transmission is suspended. Xon pacing is not recommended if binary data will be sent to
the signal generator via RS-232 as errors may occur. Toggle
Trans/Recv Pace None Xon to
None to turn off Xon pacing.
Preset N/A
Choices None or Xon
Location Page 247
Remarks The pace state is not affected by a preset or by a power cycle.
Triangle
Supported PSG-A Series
This softkey enables you to specify a triangle wave as the modulation waveform for the
internally generated, ac-coupled signal.
Preset N/A
Range N/A
Location Page 230, Page 235, Page 237, Page 240
Remarks The selected waveform applies only to the path configuration you have
currently selected.
