Agilent Technologies PSG Series User Manual

Signal Generator Overview
Front Panel Display
Chapter 1 11
Front Panel Display
Figure 1-2 shows the front panel display. The LCD screen will display data fields,
annotations, key press results, softkey labels, error messages, and annunciators that
represent various active functions of the signal generator. Descriptions are provided for each
feature of this interface.
Figure 1-2 Front Panel Display Diagram
3. Annunciators
4. Amplitude Area
1. Active Entry Area
5. Error Message Area 7. Softkey Label Area
6. Text Area
2. Frequency Area
