Key Reference
R
Chapter 5198
R
Ramp
Supported PSG-A Series
This softkey enables you to specify ramp, either positive or negative, as the modulation
waveform for the internally generated, ac-coupled signal.
Preset Positive
Choices Positive or Negative
Location Page 230, Page 235, Page 237, Page 240
Remarks This key is active only when you have selected the internal source to
operate as a function generator.
Recall
Supported All
Use this hardkey to access a menu of softkeys that enables you to select or delete
registers and sequences.
Preset RECALL Reg
Choices RECALL Reg Select Seq Delete Seq[0] Reg[0]
Delete All Reg
in Seq[0]
Delete All Sequences
Location Page 243
Remarks None
