10 Intellex
®
LT Digital Video Management System
Rear Panel
18. Video Out — This BNC connector provides a composite
video signal of the live display to an optional live monitor.
19. External Cable Connector — An external cable connects
this DB37-P female connector to #4 above.
20. Video Out — This BNC connector provides a composite
video signal of the Call Monitor card to the optional call
monitor.
21. External Cable Connector — An external cable connects
this IDC34 male header connector to #3 above.
22. Modem card — The optional modem card is installed in this
position. An RJ11 telephone jack connects to a standard
analog telephone line connection.
