User Manual – Rev BE AMETEK Programmable Power
MX Series 218
300 VAC Range Volt Full-scale: Program the output to 240.0 volts and 60 Hz. Once
the output settings are made, turn on the ALC mode
and allow the output on all phases to settle. Next,
proceed to the output calibration screen. Select the
VOLT FS parameter and enter the set voltage in the
full-scale calibration window followed by the ENTER
key. A value between 0.9 and 1.1 will appear in the
window. Save this value by pressing the SET.
300 VAC Range Volt HI Freq: [Applies to MX Series I only] Program the output to
240.0 volts and 400 Hz. Go to the OUTPUT CAL screen
and select the V HI FREQ parameter. Adjust the output
with the shuttle for an output of 240.0 ± 0.05 volts.
Repeat the 60 and 400 Hz adjustments until the output
is within ±0.05 volts of the programmed value. Save
this value by pressing the SET key.
6.4.4 Output Cal 200 V DC Range (Series I only)
200 VDC Range Volt Zero: [Applies to MX Series I only] Press the PROGRAM key.
Select the MORE option to go to the PROGRAM 2
screen. Highlight the VOLT MODE parameter and select
the DC Mode by moving the shuttle. Press the
PROGRAM key and select the 400 VDC Range. Program
0.0 VDC. Go to the OUTPUT CAL screen and adjust the
VOLT ZERO for 0.0 ± 0.005 volts DC on the output.
Save this value by pressing the SET key.
200 VDC Range + Full-scale:[Applies to MX Series I only] Program +160.0 volts DC.
Once the output settings are made, turn on the ALC
mode and allow the output on all phases to settle. Next,
proceed to the output calibration screen. Select the
VOLT +FS parameter and enter the set voltage in the
full-scale calibration window followed by the ENTER
key. A value between 0.9 and 1.1 will appear in the
window. Save this value by pressing the SET key.
6.4.5 Output Cal 400 V DC Range (Series I only)
400 VDC Range Volt Zero: Press the PROGRAM key. Press the PROGRAM key and
select the 400 VDC Range. Program 0.0 VDC. Go to
the OUTPUT CAL screen and adjust the VOLT ZERO for
0.0 ± 0.005 volts DC on the output. Save this value
by pressing the SET key.
