Ametek MX Series User Manual

User Manual – Rev BE AMETEK Programmable Power
MX Series 23
Individual Cabinet Models
Output Parameter
MX22.5
MX3 0
MX4 5
V Hi: 225 A
MX22.5-3 / MX2 2.5-3Pi, per
phase
V Lo: 150 A
V Hi : 7 5 A
V Hi: 450 A
MX3 0 -3 / MX30-3Pi / MX45-3 / MX45-3Pi, per phase
V Lo: 300 A
V Hi: 150 A
AC Mo d e
-333 Op t i on
MX22.5-1 / MX22.5-3Pi 1Phs
V Lo : 4 05 A
V Hi : 2 02.5 A
MX22.5-3 / MX22.5-3Pi, per
phase
V Lo : 1 35 A
V Hi : 67.5 A
MX3 0 -1 / MX30-3Pi 1Phs / MX45-1 / MX45-3Pi 1Phs
V Lo : 810 A
V Hi : 405 A
MX3 0 -3 / MX30-3Pi / MX45-3 / MX45-3Pi, per phase
V Lo : 270 A
V Hi : 135
Fr e quency
Range:
Standard: 16 Hz - 819.0 Hz (for –HV option range, 45 Hz – 819.0 Hz)
-LF option: 16 Hz - 500.0 Hz
-HF option: 16 Hz – 905 Hz
Resolution:
0.01 Hz from 16.00 to 81.91 Hz
0.1 Hz from 82.0 to 819.0 Hz
Accuracy:
± 0.01 %
±0.25 % for –FC o p t io n
Phase (3 phase mode)
Range:
Phase B/C relative to phase A
0.0 to 360.0°
Resolution: 0.1°
Accuracy:
16 Hz - 100 Hz: < 1.5°
100 Hz - 500 Hz: < 2°
> 500 Hz: < 4°
±0.25 % for –FC option
Ext. Sync Mode (not available with -FC o p t io n )
Input: Isolated TTL input for external frequency control. Requires 5V at 5 mA for logic high.
Accuracy:
Ext. Sync to phase A with fixed Ext. Sync Frequency input:
16 Hz - 100 Hz: < 2°
100 Hz - 500 Hz: < 3°
> 500 Hz: < 4°
