2.1.3 AC Measurements
Measurement specifications apply to MX22.5-3 / MX22.5-3Pi / MX30-3 / MX30-3Pi /
MX45-3 or MX45-3Pi in three-phase mode. See notes for other models and
configurations.
Parameter
Range
Accuracy (±)
Resolution
Frequency 16.00 - 820.0 Hz 0.01% + 0.01 Hz
0.01 to 81.91 Hz
0.1 to 500 Hz
RMS Vo l t a g e 0 - 400 Volts
0.05V + 0.02%, <100 Hz
0.1V + 0.02%, 100-820 Hz
0.01 Volt
RMS Current 0 - 150 Amps
0.15A + 0.02%, <100 Hz
0.3A + 0.02%, 100-820 Hz
0.01 Amp
Peak Current 0 - 400 Amps
0.15A + 0.02%, <100 Hz
0.3A + 0.02%, 100-820 Hz
0.01 Amp
VA P o we r 0 - 1 5 KVA
30 VA + 0.1%, <100 Hz
60 VA + 0.1%, 100-820 Hz
10 VA
Real Power 0 - 1 5 KW
30 W + 0.1%, <100 Hz
60 W + 0.1%, 100-820 Hz
10 W
Power Factor
( > 0 . 2 k VA)
0.00 - 1.00
0.01, <100 Hz
0.02, 100-820 Hz
0.01
NOTE: Accuracy specifications are valid above 100 counts. For current and power measurements, specifications apply from 2% to 100% of
measurement range. Current and Power range and accuracy specifications are times three for MX22.5-1, MX4 5 -1, MX60, MX90
a n d MX1 35 or MX30-3Pi / MX45-3Pi in single-phase mode.
NOTE: Power factor accuracy applies for PF > 0.5 and VA > 50 % of max.
2.1.4 DC Measurements
Parameter
Range
Accuracy (±)
Resolution
Vo l t a g e 0 - 400 Volts 0.5 Volts 0.1 Volt
Current 0 - 400 Amps 0.5 Amps 0.01 Amp
Power 0 - 10 kW 30 W 10 W
NOTE: Accuracy specifications are valid above 100 counts. For current and power measurements, specifications apply from 2% to 100% of
measurement range. Current and Power accuracy and resolution specifications are times three for MX30-1, MX45-1, MX60, MX90 and
MX135 or MX22.5-3Pi/ MX3 0 -3Pi / MX45-3Pi in single-phase mode.
