User Manual – Rev BE AMETEK Programmable Power
MX Series 36
2.6.1 -HV Option Specifications
The -HV option provides an AC only output range of 0 to 400 Vac L-N. Specifications
unique to the -HV option are shown in the table below.
Output Parameter
MX22.5
MX3 0
MX4 5
MX6 0
MX9 0
MX135
Mo d e s
Pi Controller
AC On l y
Voltage:
Ranges (L-N) :
0 -400 V
Resolution:
0.1 V
Accuracy:
± 0.25% of Full Scale / ± 1.0 Vac rms
Output Coupling
AC c o u p l e d
Power (total power for all phases, either range, at full scale voltage)
AC Mo d e 22.5 KVA 3 0 KVA 4 5 KVA 6 0 KVA 9 0 KVA 135 KVA
Current
NOTE: Current, maximum amps per phase available between 50 and 100 % of voltage range.
AC Mo d e
MX22.5-1 56.25 A
MX22.5-3, per phase
18.75 A
MX3 0 -1
76.5 A
MX3 0 -3, per
phase
25.5 A
MX4 5 -1
112.5 A
MX4 5 -3, per phase
37.5 A
MX6 0 -3, per phase
50 A
MX9 0 -3, per phase
75 A
MX135-3, per phase
112.5 A
NOTE: Current derates linearly from 50% of voltage range to 20% specified current at 5% of voltage range.
Peak Current
AC Mo d e
MX22.5-1 168.75 A
MX22.5-3, per phase
56.25 A
MX3 0 -1
337.5 A
MX3 0 -3, per
phase
112.5 A
MX4 5 -1
337.5 A
MX4 5 -3, per phase
112.5 A
MX6 0 -3, per phase
225 A
MX9 0 -3, per phase
225 A
MX135-3, per phase
337.5 A
Frequency:
Range:
45 Hz – 819 Hz
wit h –LF option: 45 Hz – 500 Hz
wit h –HF option: 45 Hz – 905 Hz (see also –HF op t ion specification.)
