2.6.2 -XV Option Specifications
Consult factory for -XV option specifications.
2.6.3 -HF Option Specifications
The -HF option extends the maximum available output frequency from 819 Hz to
905 Hz. Some restrictions are in effect at this increased output frequency level.
All other specifications of the MX45 system remain unchanged if this option is
installed except as noted in the table below.
-HF Op t i o n :
Frequency
Range:
-HF o p t ion : 16 Hz - 905 Hz
Resolution:
0.01 Hz < from 16.00 to 81.92 Hz
0.1 Hz > from 82.0 to 819.2 Hz
1 Hz > from 820 to 905 Hz
Accuracy:
± 0.01 %
±0.25 % f o r –FC o p t i o n
Phase
Accuracy:
16 - 100 Hz: < 1.5°
100 - 500 Hz: < 2°
500 – 819 Hz: < 4°
819 – 905 Hz: < 5°
Vo l t a g e
High Voltage Range
Maximum voltage at 905 Hz is 290 Vrms
Maximum frequency at 300 Vrms is 875 Hz
See Fig u r e 2-3
Low Voltage Range
Maximum voltage at 905 Hz is 145 Vrms
Maximum frequency at 150 Vrms is 875 Hz
See Fig u r e 2-4
-HV Voltage Range
Maximum voltage at 905 Hz is 386 Vrms
Maximum frequency at 400 Vrms is 875 Hz .
NOTE: If the voltage or frequency settings shown here are exceeded for any length of time (> 1
sec), the MX may shut down generating an over temperature fault to protect itself.
