Instruction Format:
ALU/MAC operation with Data Memory Read, Instruction Type 4:
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 1 1 G 0 Z AMF Yop Xop Dreg I M
ALU/MAC operation with Program Memory Read, Instruction Type 5:
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 1 0 1 0 Z AMF Yop Xop Dreg I M
Shift operation with Data Memory Read, Instruction Type 12:
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 0 0 1 G 0 SF Xop Dreg I M
Shift operation with Program Memory Read, Instruction Type 13:
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 0 0 0 1 0 SF Xop Dreg I M
Z: Result register Dreg: Destination register
SF: Shifter operation AMF: ALU/MAC operation
Yop: Y operand Xop: X operand
G: Data Address Generator I: Indirect address
M: Modify register register
MULTIFUNCTION
COMPUTATION with MEMORY READ
