EControl/Status Registers
E – 13
Default bit values at reset are shown; if no value is shown, the bit is undefined at reset.
Reserved bits are shown on a gray field—these bits should always be written with zeros.
BDMA External Address
(ADSP-2181 only)
DM(0x3FE2)
15141312111098 76 5432 10
000000
0 000000000
BEAD
15141312111098 7654 3210
0000000 000000000
BIAD
BDMA Internal Address
(ADSP-2181 only)
DM(0x3FE1)
Memory-Mapped Registers
IDMA Control
(ADSP-2181 only)
DM(0x3FE0)
15141312111098 7654 32 10
IDMAA
Starting address
IDMAD
Destination memory type
0=PM, 1=DM
