4-51
• Notes on setup items
(1) Relationship between measurement frequencies and channels
The IS-95A/TSB74/J-STD-008/ARIB-T53 system uses different transmit and
receive frequencies for the same frequency channel. If a frequency channel is
selected, the relationship between the channel and the transmit/receive frequen-
cies depend on the unit to be measured (that is, signals to be measured).
RF Signal Frequency of the CDMA System
BAND Channel TX Measure Freq. (MHz) RX Measure Freq. (MHz)
800 MHz 1 825.030 870.030
(IS-95A,TSB74)
2 825.060 870.060
3 825.090 870.090
797 848.910 893.910
798 848.940 893.940
799 848.970 893.970
990 824.010 869.010
991 824.040 869.040
992 824.070 869.070
1021 824.940 869.940
1022 824.970 869.970
1023 825.000 870.000
1.9 GHz 0 1850.000 1930.000
(J-STD-008) 1 1850.050 1930.050
2 1850.100 1930.100
1197 1909.850 1989.850
1198 1909.900 1989.900
1199 1909.950 1989.950
800 MHz 1 915.0125 860.0125
(ARIB-T53) 2 915.0250 860.0250
3 915.0375 860.0375
797 924.9625 869.9625
798 924.9750 869.9750
799 924.9875 869.9875
801 898.0125 843.0125
802 898.0250 843.0250
803 898.0375 843.0375
1037 900.9625 845.9625
1038 900.9750 845.9750
1039 900.9875 845.9875
1041 887.0125 832.0125
1042 887.0250 832.0250
1043 887.0375 832.0375
1197 888.9625 833.9625
1198 888.9750 833.9750
1199 888.9875 833.9875
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
