Section 4 Operation
4-52
BAND Channel TX Measure Freq. (MHz) RX Measure Freq. (MHz)
1.7 GHz 1 1750.050 1840.050
(KOREA-PCS) 2 1750.100 1840.100
3 1750.150 1840.150
598 1779.900 1869.900
599 1779.950 1869.950
600 1780.000 1870.000
601 1715.050 1805.050
602 1715.100 1805.100
603 1715.150 1805.150
1298 1749.900 1839.900
1299 1749.950 1839.950
1300 1750.000 1840.000
• Main function keys:
1st page
[TX Measure] F1: Displays the TX Measure (transmitter measurement) function keys appear on F7 to
F12.
[RX Measure] F2: Displays the RX Measure (receiver measurement) function keys appear on F7 to F12.
[Call Processing] F4: Displays the Call Processing (call processing test) function keys appear on F7 to F12.
2nd page
Call Processing main function keys:
The following main function keys are displayed depending on the Call-Processing execution state.
[NW Originate] F2: Executes NW Originate sequence for the MT8801C to call DUT.
[NW Release] F2: Executes Network (NW) Release sequence.
[Register] F4: Executes Forced Registration.
[Start] F5: Executes the Call-Processing function for the MT8801C to enter the “Idle” state.
[Stop] F5: Stops the Call-Processing function for the MT8801C to enter “Stop” state.
• Function keys for Stop State CDMA transmitter measurement:
1st page
[Modulation Analysis] F8: Displays the Modulation Analysis screen.
[Occupied Bandwidth] F11: Displays the Occupied Bandwidth screen.
[Power Meter] F12: Displays the Power Meter screen.
2nd page
[Setup TX Parameter] F9: Displays the Setup TX Measure Parameter screen.
[Setup Gated Power Template] F10:
Displays the Setup Template screen.
[Spurious close to the Carrier] F11:
Displays the Spurious close to the Carrier screen.
[Spurious Emission] F12: Displays the Spurious Emission screen.
