4-91
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
(10) Spurious close to the Carrier measurement: Spurious close to the
Carrier screen, Setup Spurious Template screen
Measures adjacent spurious of transmission signal (of transmitter) using param-
eters set on Setup Common Parameter screen (paragraph 4.3.5).
Also, sets the spurious waveform template (amplitude standard line) at Setup
Spurious Template screen, and can save/recall upto 100 types to/from an FD
(3.5-inch floppy disk) at Save Spurious Template screen or Recall Spurious
Template screen. Note that the template can be displayed only at 5 MHz fre-
quency span.
(a) Measurement of Spurious close to the carrier: Spurious close to the carrier
screen
• Display the Spurious close to the Carrier screen according to the following steps:
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Func on to display the Main Menu at the bottom of the screen.
2. [TX & RX Tester] F1 Sets TX Test mode.
The Setup Common Parameter screen appears.
3. [TX Measure] F1 Displays the first page of the TX Measure menu.
4. [Next Menu] [ ] Displays the second page of the TX Measure menu.
5. [Spurious close to the Carrier] F11
Displays the Spurious close to the Carrier screen.
To Next Page
