Section 4 Operation
4-92
Main Func
On Off
1
21
Adj.CH
MT8801 99-12-02 06:15:00 Measure : Single
<< Spurious close to Carrier(CDMA) >>
Channel
#
Level
#
->
Back
Screen
*
*
Measure
Method
Unit
Range
Adjust
Calibration
*
Channel : 1092CH Frequency : 887.650 000MHz Level : -2dBm
M
Tx Power (Modulation):
Marker :
Offset Frequency
-1.27 MHz
Power (RBW: 30kHz)
-70.12 dB
Power (RBW: 1 MHz)
-50.56 dB
-1.17 dBm
Method : Spectrum
-10
Span : 5.00 MHz RBW : 1 MHz
[dB]
-20
-30
-40
-50
-60
-70
-80
-90
-100
Template : IS-95(Relative)
Main Func
On Off
1
1
Adj.CH
->
Back
Screen
*
Recall
Spurious
Template
Setup
Spurious
Template
2
->
Offset Freq. vs Power
-1.980 MHz : -52.34 dB
-0.900 MHz : -7.60 dB
0.900 MHz : -7.32 dB
1.980 MHz : -51.94 dB
*
Storage
Mode
Span
#
RBW
#
Fig. 4-14 Spurious close to the Carrier Screen (Measurement method: Spectrum, RBW: 1.23 MHz)
Notes:
1. When RBW is 30 kHz, the measurement waveform by spectrum analyzer is
displayed.
When RBW is 1 MHz or 1.23 MHz, the measurement waveform by spec-
trum analyzer and the accumulated data by digital processing are displayed.
2. Offset Freq. vs Power displays the measured results by the selected RBW.
3. Template judgment is performed for the measured results by the selected
RBW.
4. When Data Rate is 1/2, 1/4, or 1/8; Tx Power (Modulation) is displayed.
• Function key
Main function key:
[Channel] F1: Changes the Channel number.
[Level] F3: Changes the reference level.
[Span] F4: Changes the frequency span.
[RBW] F5: Displays the resolution bandwidth (RBW) menu. 30kHz (Initial value),
1 MHz, 1.23 MHz settings are possible.
When the frequency span is 25 MHz, this menu is not displayed, and RBW is fixed to
30 kHz.
