Using the APP Recorder 6-47
3. In the This Station ID box, type the Recorder ID, which was setup in the Recorder Configuration
window. For information on setting the Recorder ID, see Configuring the Main Configuration
Settings.
4. From the COM list, select the desired communication port.
5. Are you using an RS232 port or a TCP/IP network protocol?
 If you are using a RS232 port, select RS232, then from the Baud Rate list select a baud rate
that will work with your RTU.
 If you are using a TCP/IP, select Network, then enter the port number.
5. Sending analog floating points on Class 0: Check this box if you want to send values converted
to Floating Point instead of HEX values to the RTU. Otherwise, for the RTU to receive HEX leave
unchecked.
6. From the menu bar, click Save.
The APP-601 Recorder accepts the DNP-3 objects and variations shown in the following table.
Table 13: DNP-3 Objects and Variations
Object
Variation
Description
Request
Function
Codes
(dec)
Request
Qual
Codes
(Hex)
Response
Function
Codes
(dec)
Response
Qual
Codes
(Hex)
1
1
Binary Input
1
06
129
2
2
Binary Input
Change with
Time
1
06
129
28
30
4
16-Bit
Analog Input
without Flag
1
06, 01, 28
129
01, 28
60
1
Class 0 Data
1
06
129
01
100
1
Short
Floating
Point
1
06, 01, 28
129
01, 28
