APP APP-601 - System Computer Specifications

Specifications 2-5
2.6 Communications
Recorder to master station
Ethernet 10/100Mbit, TCP/IP (Fiber optional)
Modem 56K
Chassis to chassis
Ethernet 100Mbit, UDP (Fiber optional)
DNP-3
Ethernet 10/100Mbit, TCP/IP (Fiber optional)
RS232 (9-Pin Connector)
PMU
Ethernet 10/100Mbit, UDP or RS232 (9-Pin Conn)
2.7 System Computer
2.7.1 Choice #1 APP-601 Computer Chassis
Operating system
XP Professional or Windows 7, and 10
Processor
Atom D510 Dual-Core 1.66Ghz Fanless
RAM
2GB DDR2 667MHz SODIMM Module
Flash
On Board Compact (16GB is STD, larger is
available)
Internal HDD
500GB Min.
External HDD, CDRW, DVDRW
Option
Ports
2x Programmable RS232/422/485 (Com1 & 2)
2x RS-232 (Com3 & 4)
2x Ethernet (1 for DSP, 1 for LAN) Intel 82574
1x Ethernet (Spare) Realtek RT8111C
5x USB2 (4 on back panel, 1 on front panel)
2x eSATA
2x PS2 (Keyboard & Mouse)
1x VGA, 1x Modem 56K , 1x Sound, 1x MIC
1x LVDS (for LVDS Interface Panel)
Display
Option, See APP-601 Mon./Keyboard Chassis
Keyboard
Option, See APP-601 Mon./Keyboard Chassis
Touchpad
Option, See APP-601 Mon./Keyboard Chassis
Temperature
5 to 55° C with standard HDD
-25 to 70° C with Extended Temp Range HDD
(80GB Max) or Solid State Drive
Solid State Drive
Option (SLC Recommended)
Power Button
Recessed, Non-latched with Blue LED (for off
hold for 5 seconds)
Reset Button
Recessed, if pushed it executes a hard reset
