APP APP-601 - Event Inputs; Power Supply

Specifications 2-3
2.2 Event Inputs
Max channels per chassis
80
Channels per card
8
Channel type
DFR, SER or Both
Standard input voltage range
45-250VDC
Optional input voltage
24VDC or internally wet
Contact configuration
Programmable normally open/normally closed
Configuration
Isolated or common return
Channel to channel isolation
≥ 3500VDC
Channel to ground isolation
≥ 3500VDC
Connector type
Pluggable, 16 pole
Max wire size
14AWG
2.3 Power Supply
AC Range
88-264Vac (50/60Hz)
DC Range
86VDC to 373VDC (48VDC Option)
Power draw @ 125VDC
90W, 54 analog channels & 96 event channels
Input to ground isolation
≥ 3500VDC
