Table 10: Configuring Automatic Tasks—Options in the Call Master List
If a fault triggers the Recorder
Select this option
Also set the values of
these fields
What should it
upload?
When?
A Fault Summary
File
Always
Yes– always
(Send FSum Only)
Max #Faults in FSum
box on the Main tab
This determines the
number of fault files in
the Fault Summary
Record.
A Fault Summary
File, and associated
data
Always
Yes – always
(Send FSum and
Data)
Data means these only
check boxes
These determine the type
of data sent.
If all of the boxes are
unchecked, then all of the
types of data will be sent.
A Fault Summary
File
Only when
certain
conditions occur
Yes – if logic true
(Send FSum Only)
Max #Faults in FSum
box on the Main tab
Logic (OR=1, AND =&)
box
Data means these only
check boxes
A Fault Summary
File and associated
data
Only when
certain
conditions occur
Yes – if logic true
(Send FSum and
Data)
Logic (OR=1, AND =&)
box
Data means these only
check boxes
A Fault Summary
File (always)
and associated data
(sometimes)
Always print a
Fault Summary
Report
but
Print all analog
waveforms and
all event graphs
only when
certain
conditions occur
Yes – always
(FSum), if logic
true (Data)
Max #Faults in FSum
box on the Main tab
Logic (OR=1, AND =&)
box
Data means these only
check boxes
