Hardware 4-5
4.3.2 APP-601 Computer Control Chassis Specifications
APP-601 Computer Control chassis specifications are listed in the following table.
Table 2: APP-601 Computer Control Chassis Specifications
Item
Description
Operating system
XP Professional or Windows 7, and 10
Processor
Atom D510 Dual-Core 1.66Ghz Fanless
RAM
2GB DDR2 667MHz SODIMM Module
Flash
On Board Compact (16GB is STD, larger is
available)
Internal HDD
500GB Min.
External HDD, CDRW, DVDRW
Option
Ports
Notes:
1) Use the Enet marked “DSP Enet” to connect the
computer chassis to the ethernet switch provided
with the system.
2) Use the Enet marker “LAN Enet” to connect
your substation LAN.
3) If using a USB keyboard we recommend the use
either USB port directly next to the PS2 ports and
is housed with the 3
rd
ethernet port.
2x Programmable RS232/422/485 (Com1 & 2)
2x RS-232 (Com3 & 4)
2x Ethernet (1 for DSP, 1 for LAN) Intel 82574
1x Ethernet (Spare) Realtek RT8111C
5x USB2 (4 on back panel, 1 on front panel)
2x eSATA
2x PS2 (Keyboard & Mouse)
1x VGA, 1x Modem 56K, 1x Sound, 1x MIC
1x LVDS (for LVDS Interface Panel)
Display
Option, See APP-601 Mon./Keyboard Chassis
Keyboard
Option, See APP-601 Mon./Keyboard Chassis
Touchpad
Option, See APP-601 Mon./Keyboard Chassis
Temperature
5 to 55° C with standard HDD
-25 to 70° C with Extended Temp Range HDD
(80GB Max) or Solid State Drive
Solid State Drive
Option (SLC type recommended)
Power Button
Recessed, Non-latched with Blue LED (for off
hold for 5 seconds)
Reset Button
Recessed, if pushed it executes a hard reset
Front Panel LED Indicator
12V Power Green, Solid On When Power is OK
Rear Panel LED Indicators
Watchdog (WD) Yellow, Indicates the status of
the watchdog timer. When started the LED flashes
and when the timer expires the LED lights
Hard Drive (HD) Red, When the SATA HD is
operating the LED flashes
Compact Flash (CF) Green, When the CF is
operating the LED flashes
