Using the APP Recorder 6-7
To Print the Recent Fault Summary
In the APP Recorder window, from the File menu, click Print Recent Fault Summary.
The report is sent immediately sent to the printer you selected in the procedure, Selecting and
Configuring the Printer.
6.5.4 Printing the Recent Fault Summary with a Graph
You can preview or print a fault summary report that includes both analog and event graphs. You can
specify parameters including the Y-scale, print channels, print range, channels per page, and event channel
formatting.
To Print the Recent Fault Summary with a Graph
1. In the APP Recorder window, from the File menu, click Print Recent Fault Summary +
Graph.
A window appears in which you can specify report configuration parameters.
2. Specify the report configuration parameters and then click OK.
The report is sent immediately sent to the printer you selected in the procedure, Selecting and
Configuring the Printer.
6.6 Exiting the APP Recorder
You can exit the APP Recorder for maintenance or troubleshooting purposes. When you exit the APP
Recorder, the APP Driver is automatically exited as well.
If you have set an administrator password, then you must enter the password before exiting the APP
Recorder. See Setting the Administrator Password for more information.
Stopping the APP Recorder Program takes the APP Recorder
OFFLINE. No recording will be performed while the APP Recorder
Program is stopped.
Note: If the APP Monitor check box is checked in Tools/Windows logon and startup, APP
Recorder will automatically restart itself in no more than 60 seconds.
To avoid auto restart, do the following prior to exiting
1. Go to Windows Task Manager by pressing CNTL-ALT-DEL
2. Click Start Task Manager
3. In the Process Tab, single click (Select)APP Monitor
4. Click End Process
To Exit the APP Recorder Program
1. From the APP Recorder window File menu, click Exit.
2. Has an administrator password been set?
a) If yes, then a message box appears. Enter the password and click OK. The program is
stopped immediately.
b) If no, then the program is stopped immediately.
