Hardware 4-4
4.3.1 Important APP-601 Computer Circuit Board Connector Points
APP-601 computer circuit board connector points are listed in the following table.
Table 1: APP-601 Computer Circuit Board Connector Points
Connector Point
Description
1) CN2
If the computer fails to boot this 2-pin jumper clears the BIOS content
stored in CMOS and restores the default settings. Pin#1 and pin#2 of CN2
are jumpered and the system restores to default BIOS settings
2) SATA Connector
The SATA connector/port is used for the hard drive. It supports data
transfer up to 3.0 Gbits/s (300MB/s). The SATA connector is compatible
with 2.5” hard disk drives or solid state drives. The HDD or SSD must be
installed into the SATA connector with the provided HDD bracket.
3) Mini PCIe Connector
The mini-PCIe connector provides function expansion via installation of a
third party mini-PCIe module complying with PCIe standard 1.1, such as a
WiFi module, 3.5G module or other expanding function.
