Using the APP Recorder 6-31
2. In the box, type the IP addresses. Press the Enter key between each IP address.
3. To delete an IP address, right-click the IP address and click Delete.
Note: You can also use the Undo, Cut, Copy, and Paste options from the pop-up
menu.
4. From the menu bar, click Save.
6.7.19 Printing Recorder Configuration
You can print the configuration information by clicking Print at the top of the screen then selecting Print
Preview or Print. Print Preview allows you to review the report, save, change the printer preferences, and
print.
6.8 Editing the Point Assignment Record
The Point Assignment Record is a user-defined record that is used by the APP Recorder to control system
operation, perform calculations, and perform analysis. A Point Assignment Record contains information
concerning the recorder hardware, analog channels, analog triggers, events, sampling rates, and different
types of recording. The Point Assignment Record is saved in the setup folder and is structured Rxxx.par
where xxx is the recorder number.
If your company provides point assignment information, APP factory personnel will enter that information
into the APP Recorder before shipping it to you. You can edit a Point Assignment Record via the APP
Recorder Software or the APP ClearView Software. The Point Assignment Record file can be downloaded
from the master station (APP ClearView) to the APP Recorder or vice versa.
In the APP Recorder, you can access the Point Assignment Record from the Edit menu of the APP
Recorder window. For complete details on how to create and edit the Point Assignment Record, see the
APP ClearView Operating Manual.
Note: If an administrator password is defined, only the administrator has privileges to save a
newly created Point Assignment Record or save changes to an edited Point Assignment
Record.
6.9 Editing the Line Group Record
The Line Group Record is a user-defined record. Here channels that form a line group are linked together.
This permits the APP Recorder to perform distance to fault calculations, various power calculations, and
provides a quick convenient means for viewing oscillograms for different line groups. The Line Group
Record is saved in the setup folder and is structured RxxxLines.inf where xxx is the recorder number.
If your company provides line group information, factory personnel will enter that information into the
APP Recorder before shipping it to you. In addition, you can create and edit a Line Group Record can be
created or edited via the APP Recorder or the APP ClearView. The line group file can be downloaded from
the master station (APP ClearView) to the APP Recorder or vice versa.
In the APP Recorder, you can access the Line Group Record from the Edit menu of the APP Recorder
window. For complete details on how to create and edit the Line Group Record, see the APP ClearView
Operating Manual.
Note: If an administrator password is defined, only the administrator has privileges to save a
newly created Line Group Record or save changes to an edited Line Group Record.
