Using the OScope 8-5
8.2.8 Bottom Tray
The bottom tray shows the chassis number being viewed, the run/stop status of the OScope, the fault timer,
and the sync status of the fault timer. If the sync status is followed by “unknown”, the recorder cannot
detect any IRIG-B input. See Other Information for time quality details.
8.3 Reinitializing the OScope Window
Reinitialize the APP OScope window to restart the OScope and update the Display Window.
To Reinitialize the OScope Window
In the APP OScope window, from the File menu, click Reinitialize.
8.4 Exiting the OScope Window
When you exit the OScope window, the APP Recorder returns to its normal, online status.
To Exit the OScope Window
In the APP OScope window, from the File menu, click Exit.
8.5 Editing the Point Assignment Record
You can edit the Point Assignment Record from within the OScope window.
In the APP OScope window, from the Edit menu, click Edit Point Assignment Record.
The Point Assignment Record window appears. For complete details on how to create and edit the
Point Assignment Record, see the APP ClearView Operating Manual.
8.6 Viewing Driver Status
You can view detailed information about the status of a channel, including key messages sent between the
system DSP boards and the system computer.
To View the Driver Status
In the APP OScope window, from the Status menu, click Show Driver Status.
The DSP Board Communication Status window appears.
