Using the APP Recorder 6-26
6.7.12 Defining a Boolean Logic Equation
You can define a Boolean Logic equation to automatically filter, or limit, when the APP Recorder does any
or all of the following:
 Calls the master system
 Prints the Fault Summary File and fault-related data
 Sends an email notification
 Sends transient fault record via FTP
Note: You can define only one logic entry.
The following table lists the available equation variables and field entries.
Table 12: Defining a Boolean Logic Filter—Variables and Entries
Entry
Description
0
False, nothing will pass filter
1
True, everything passes filter
Blank (Nothing Entered)
True, everything passes filter
T1, T2, T3…..
Represents Analog Channels
t1, t2, t3…..
Also Represents Analog Channels
E1, E2, E3….
Represents Event Channels
e1, e2, e3….
Also Represents Event Channels
6.7.13 Performing a Test Upload
You can use the Upload tab to test the upload process. This tab allows the transfer of any file from the
local directory to the remote directory. If the file is successfully transferred, an “Upload Succeed” message
will appear in the FTP Status pane. If the file is not transferred, an “Upload Fail” message will appear
instead.
