Using the APP Recorder 6-24
6. (Required) In the User ID field, type the user ID to log in to the host.
7. (Required) In the Password field, type the password to log in to the host.
8. Do you want to use a proxy server?
If yes, then select the Proxy Server check box. In the Proxy Server box, type the name of the
proxy server. In the Proxy Port box, type the port number for the proxy server.
If no, skip to the next step.
9. Do you want to create a logic filter to identify when the transient record should be sent to the host
directory?
If yes, then select the Auto Upload Fault Files if Logic Filter (LF) True check box. On the
Automatic Tasks tab of the Recorder Configuration window, verify that the Logic box
contains the appropriate value. For more information on completing the Logic box, see
Error! Reference source not found..
If no, skip to the next step.
10. Max #Upload/hr box, enter the maximum number of fault records to be sent to the host directory
per hour. Specify a limiter here to stop the host directory from being inundated with data in the
event that the APP Recorder has an unexpected runaway tripping event.
Note: You can reset the counter manually via the Reset Upload button. The Reset
Upload button is for emergency purposes if the maximum upload number has
been exceeded, but you still want other fault records to be sent.
11. Max #Retry of each Upload box, enter a limiter that determines how many times the software
will try to send a new record to the host directory. If the limit is reached due to some connection or
setting problem, a message will appear in the APP Recorder trace file.
12. Time Between each Retry : Randomized Between, enter the two times in seconds, between
which FTP retries should occur. APP Recorder will attempt at random intervals between the range
specified, to resend data.
13. Delay 1st Send (by retry time) check box. Check this to delay 1
st
send by the Retry time
specified above.
14. From the menu bar, click Save and then click the Directory tab.
The Directory tab appears, as shown in the following Figure 34: FTP Remote Directory Setup
Window
